Technical specifications

• Rated operational current: 18…370 A- Operational voltage: 208…600 V AC
• Wide rated control supply voltage: 100…250 V AC, 50/60 Hz

Features

• Voltage ramp and torque control for both start and stop
• Two-phase controlled- Current limit – Kick-start
• Built-in bypass for energy saving and easy installation
• Illuminated display that uses symbols to become language neutral
• External keypad rated IP66 (Type 1, 4X,12) as an option
• Analog output for display of motor current

Protections

• Electronic overload protection
• Underload protection
• Locked rotor protection

Communication

• Built-in Modbus RTU
• Fieldbus communication with fieldbus plug adapter and fieldbus plug
